Connection channel between the inner and outer socket shell. • Available in 16mm or 21mm diameters • Beige or black color options

Used to connect the electrodes in myoelectric systems to a:9E169 Coaxial Plug13E205 MyoRotronic9E369/9E370 4-in -1 LS Controller or 9E420 7-in-1 Controller13E190 Distributor or 10S7 Electric Wrist Rotator

Lamination ring for System Electric Hands or System Electric Greifers with lamination protection cover for bonding.

The MyoRotronic is compatible with all ottobock Myobock System Electric Hands and System Electric Greifers with Quick-Disconnect Wrist and enables proportional or digital control of the 10S17 Electric Wrist Rotator.5 different programs can be selected using the 757T13 Myo Select and allow individual adaptation to the respective patient. One or two 13E200 Electrodes or 13E202 Suction Socket Electrodes or a combination of one electrode and a 9X50/9X52 Linear Control Element are used to control the 13E205 MyoRotronic.Includes:MyoRotronic13E183 Buzzer for acoustic feedback on the switchoverThe 757T13 MyoSelect is required to select programs and adjust the 13E205 MyoRotronic. When using the 10S17 Electric Wrist Rotator and the 13E205 MyoRotronic, the distance between the residual limb end and wrist must be at least 65 mm . The rotation can be switched off using the 9X24 Connection Cable.

The Electric Wrist Rotator provides electrical rotation that can be operated with all ottbock System Electric Hands that are equipped with the Quick Disconnect Wrist.Required for pronation and supination of the handIf muscular tension is not sufficient for operation with the 13E205 MyoRotonic, the 10S17 can be controlled by the 9X14 Harness Pull Switch, the 9X18 Traction Switch, or the 9X25 Rocker SwitchIncludes:11S4 Lock Ring11S61 Wrist Drive with Coaxial Plug11S25 Lock Ring9E85 Protective Cap9E363 Drive Unit9E365 Protection Plug

For connecting the two electrodes and battery.

Includes: Coupling Piece 11S4 Lock Ring

The 13E200 Myobock Electrode lessens sensitivity to low and high frequency interferences to minimize prostheses operation interruption and provide noise filtration.

Electrode cable connection with IDC termination, with 13E206 Electrode Accessories, without electrode cable. Creates an airtight seal between the inner socket and outer socket when embedded into a mounting suspension of elastic material. The Suction Socket Electrode also prevents sweat from penetrating between the outer and inner socket, preventing damage to the electrical and mechanical components caused by corrosion.The Suction Socket Electrode can not only be used for standard fittings, but is also suitable for application in suction sockets. Combining the suction socket electrode with a 12V10 Tube Valve for a suction socket creates a vacuum effect in the socket, ensuring optimal linkage between the residual limb and the socket.Shielding and filtering technologies largely protect the 13E202 Suction Socket Electrode against high frequency interference caused by cell phones, walkie-talkies, computers or anti-theft systems in shopping centers so that the correct function of the myoelectrically controlled prosthesis is not affected. The electrode contacts are made from pure titanium and are suitable for people with allergies.Includes:(1) 13E200 electrode(1) 13E80 adjustment tool(1) 13E191 casting template for inner socket(1) 13E192 lamination template(2) 507S15 lamination plate with bore(1) 13E201 electrode accessories for vacuum-formed inner sockets(2) 503F3 socket screw with Allen headThe following products are also required:13E129=* electrode cable

757L35 MyoCharge Integral charger is designed to facilitate quick and easy charging of the embedded MyoEnergy Integral batteries (757B35=0, 757B35=1 or 757B35=3) while in the socket wall.Charging is done by connecting the charging plug to the charging receptacle on the outside of the socket. The integrated magnet allows for the charging plug to be easily attached to the charging receptacle. The special contour of the charging receptacle and charging plug assures the quick, reliable positioning of the two components to each other.LEDs indicate the readiness of the charger and the current battery capacityIncludes:757L35 MyoCharge Integral battery charger757L16 power supply

The MyoEnergy Integral 757B35=* is an integrated power supply system made up of several components. The charging receptacle enables battery contact, indicates the current charge status and serves to switch the prosthesis on and off and release it in an emergency. The communication cable with a 3-pin receptacle is used for the exchange of data. The supply cable establishes the connection between the battery and the respective prosthesis component. The battery consists of two cells with different capacities.Includes:Battery Lamination DummyCharging Receptacle Lamination DummyDrilling Template for Charging ReceptacleCharger must be ordered separately - 757L35 MyoCharge Integral

The 12V10 suction socket valve allows air to escape from the prosthesis when the residual limb moves within the socket, but prevents air from entering.Used in conjunction with the 13E202 Suction Socket Electrode, the 12V10 Valve:Keeps air out and prevents moisture from leaving the pull-in tubeUses standard pull-in tubes and can be retrofit into existing prosthesisProvides an airtight seal between the inner and outer socket preventing damageCreates optimal linkage between the residual limb and socket by creating a vacuum effect in the suction socket

Battery cable for 757B20 and 757B21 series batteries.For connecting the 757Z185=1 or 757Z191=1 Battery Receptacle to 9E169 Coaxial Plug, 10S17 Electric Wrist Rotator or 13E205 MyoRotronic or the 13E190 or 13E190=150 distributor.Available in two lengths: 200 mm (13E188=200) or 600 mm (13E188=600)

757L20 Lithium-Ion Battery Charger provides:Simultaneous charging of one or two 757B20/757B21 EnergyPack batteries100 – 240 (automatic adjustment) V/ACFull charging of 757B20 in approximately 3.5 hoursFull charging of 757B21 in approximately 3.0 hoursThe case is made of impact-resistant plastic materialScope of delivery includes:ChargerIncludes 757L16-4 Main Adapter with interchangeable EU and US plugsThe 4X74 car adapter cable can be ordered separately

The MyoSkin Natural Glove for men has a multi-layered design providing depth and a very vivid, natural appearance. Robust and easy to clean, the glove protects the prosthesis from dust, dirt and moisture. Designed for use with Myobock hands.Multilayered structure provides natural appearance and resilient prosthetic coveringDirt can be removed with water and soap, while tough stains can be cleaned with the 640F12 Ottobock Special CleanerColor scale 646M47 can be used for selectionMulti-Layered PVC provides depth effect for vivid, natural appearanceOuter translucent layer allows colored fibers to shine through producing luminous qualityTreated with a special surface treatment for easy clean-up

The Cosmetic Glove for Women is sized to fit, protect, and facilitate the movement of myoelectric terminal devices. Color scale 646M3 is used for matching glove color with patient’s skin tone.Applicable for protection of MyoBock terminal devicesAvailable in 18 skin shades

Pincer accessory tool for hand sizes 7, 7 1/4, 7 3/4 and 8 1/4. Pincer fits between fingers and thumb on hand and is used for grasping small objects.

The System Cosmetic Glove is designed to protect MyoBock terminal devices. It has a natural appearance, durability, and is flexible to facilitate movement of myoelectric terminal devices.Applicable for protection of MyoBock terminal devicesAvailable for hand sizes 7 ¼, 7 ¾, 8 and 8 ¼Color scale 646M3 can be used for matching glove color with patient’s skin tone

757B20 EnergyPacks are:Available in colors: 4 (757B20, 757B21), 11 (757B20-1, 757B21-1), 15 (757B20-2, 757B21-2) and Black (757B20-3, 757B21-3)Appropriate for more active patients and SensorHand Speed usersTo be used only for MyoBock Adult SystemsDesigned utilizing Lithiom-Ion technology for longer life than NiCd batteryCapable of integration into almost all socket shapes including long residual limbsFor MyoBock System, 6/7.2 Volt,For integration into all socket shapes, even in cases of long residual limbs. Compared to NiCd battery, these batteries have a lower self-discharge level, higher cell voltage and greater capacity. They have no memory effect.

Used to identify and adjust Myobock components, the 757T13 MyoSelect has an integrated display which identifies the type of component and its current control status. The multifunction button is used to select and adjust alternative control modes.757T13 MyoSelect provides:Quick, easy solution for selection and adjustment of speed or mode of controlDirect connection with Myobock terminal device without need for PCThe ability to customize speed of SensorHand Speed, MyoHand VariPlus Speed and System Electric GreiferDMC VariPlus and MyoRotronic are programmed exclusively with MyoSelectComponents must be equipped with a black coding plug for MyoSelect to have access to all available programs for a particular terminal device.

The MyoSkin Natural Glove for Women has a multi-layered design providing depth and a very vivid, natural appearance. Robust and easy to clean, the glove protects the prosthesis from dust, dirt and moisture.MyoSkin Natural Gloves are especially designed for Myobock hands.Multilayered structure provides natural appearance and resilient prosthetic coveringDirt can be removed with water and soap, while tough stains can be cleaned with the 640F12 Ottobock Special CleanerManufactured in seven colors (2, 4, 6, 8, 11, 14, 16); Use 646M47 color scale for selectionMulti-Layered PVC provides depth effect for vivid, natural appearanceOuter translucent layer allows colored fibers to shine through producing luminous qualityTreated with a special surface treatment for easy clean-upNail polish can be applied and reapplied to the finger nails and removed with acetone-free nail polish remover.
