Total Knee® 2000
Quick Links
| Part # | Description |
|---|
Product information
The Total Knee® 2000 features improved shock absorption, increased comfort and a more natural gait. Mid-swing shortening offers increased toe clearance during swing to prevent hip-hiking and 3-phase hydraulic swing control accommodates changes in walking speed. The adjustable stance flexion feature mimics the knee flexion that occurs during early stance, reducing shock and stress on the residual limb.
- Low build height
- Designed for multi-speed ambulators
- Polycentric knee with geometric locking system
- Swing control adjustments through 3-phase (3-valve) hydraulic system
- Adjustable stance flexion
- Adjustable extension promoter
Specifications
- Activity Level: K3
- Knee Design Type: Polycentric, Hydraulic Swing, Mechanical Stance Phase Lock
- Axis: Polycentric
- Swing Phase: Hydraulic
- Stance Phase: Friction, Mechanical Lock
- Control Frame Material: Aluminum
- Product Weight (g): 690
- Maximum User Weight: 220lbs (100kg)
- Maximum Knee Flexion Angle: 150 Degrees
- Proximal Connection: Threaded Adapter
- Distal Connection: 30mm Tube Clamp
- Trial Period: N/A
- Warranty: 24 months from ship date
If packaging is opened, product is not eligible for return.
Demo units are available upon request. Please contact your Account Manager to coordinate.
All items shipped ground, 2nd Day Air, and 3rd Day Air direct from the manufacturer will be a flat rate of $10 per shipment. All items shipped Next Day Air Saver will be $40 and $55.00 for Next Day Air.
| HCPCS: | L5814, L5845, L5850 |
|---|---|
| User: | Adult |
| Amputation Level: | Transfemoral (TF/AK), Knee Disarticulation |
| Activity Level: | K3 (High) |
| Swing Phase: | Hydraulic |
| Stance Phase: | Friction |
| Axis Type: | Polycentric |
| Proximal Connection: | Threaded Adapter |
| Distal Connection: | Tube Clamp |
| Weight Limit: | 100 kg (220 lbs) |
| Material: | Aluminum |
