Dynamic Vacuum System, Non-Weight Bearing
By
ottobock
Quick Links
| Part # | Description |
|---|
Product information
The Non-Weight Bearing Dynamic Vacuum System is used when offset or contracture angles do not allow fitting of the standard 4-Hole connector. The vacuum generates during walking and maintains elevated vacuum in both swing and stance phase. If the user increases their activity, the system’s pumping output increases until the pistoning in the socket is reduced and a higher vacuum equilibrium is reached.
- Separate connection plate required
- Dynamically adjusts to the user's activity level
Specifications
- Amputation Level: Transtibial
- Activity Level: K1-K4
- Housing Material: Aluminum
- Max Vacuum (inHg): 6-10
- Weight Limit: N/A
- Product Weight (g): 110
- Height (mm): 27
- Diameter (mm): N/A
- Trial Period: N/A
- Warranty: 24 months from purchase date
| HCPCS: | L5781 |
|---|---|
| User: | Adult |
| Amputation Level: | Transtibial (TT/BK) |
| Suspension Type: | Vacuum Systems |
| Weight Limit: | No Weight Limit |
| Material: | Aluminum |
