Balance™ Knee OFM1
By
Ossur
Quick Links
| Part # | Description |
|---|
Product information
Balance™ Knee OFM1 is a mechanical polycentric knee joint that is suitable for users with high safety requirements. The knee can be locked when standing and is therefore appropriate for new amputees and less mobile users.
- Locking function for a high degree of safety
- Flexion and extension can be released depending on the patient’s progress
- Increased ground clearance for a safer and more confident gait
- Rates of flexion and extension can be adapted to the user
- Simple modification of the socket connector
Specifications
- Activity Level: K1, K2
- Knee Design Type: 4-Bar Linkage, Friction Swing Phase Control
- Axis: Polycentric
- Swing Phase: Friction, Integrated Extension Spring
- Stance Phase: Friction, Adjustable Stability and Adjustable Stance Flexion
- Control Frame Material: Aluminum
- Product Weight (g): 640-770
- Maximum User Weight: 300lbs (136kg)
- Maximum Knee Flexion Angle: 150 Degrees
- Proximal Connection: Pyramid, IKF Adapter, Loop Adapter
- Distal Connection: 30mm Tube Clamp
- Trial Period: N/A
- Warranty: 24 months from ship date
If packaging is opened, product is not eligible for return.
Demo units are available upon request. Please contact your Account Manager to coordinate.
All items shipped ground, 2nd Day Air, and 3rd Day Air direct from the manufacturer will be a flat rate of $10 per shipment. All items shipped Next Day Air Saver will be $40 and $55.00 for Next Day Air.
| HCPCS: | L5611, L5845, L5850, L5925 |
|---|---|
| User: | Adult |
| Amputation Level: | Transfemoral (TF/AK), Knee Disarticulation |
| Activity Level: | K1 (Low), K2 (Moderate) |
| Swing Phase: | Friction |
| Stance Phase: | Friction |
| Axis Type: | Polycentric |
| Proximal Connection: | IKF Adapter, Loop Adapter, Male Pyramid Adapter |
| Distal Connection: | Tube Clamp |
| Weight Limit: | 100 kg (220 lbs), 125 kg (275 lbs) |
| Material: | Aluminum |
